Bergamont E-Horizon Tour 50 Wave

The Bergamont E-Horizon Tour 50 Wave electric bicycle is a trekking e-bike with a low-step aluminum frame, designed for city riding and excursions. It has a Bosch Performance Line motor and a 540 Wh PowerTube battery.

• Easy to get on and off thanks to the low frame, with a 448 mm step-over height
• 250 W Bosch Performance Line motor, assists you up to 25 km/h
• 540 Wh PowerTube battery, removable so you can charge it wherever you like
• Shimano hydraulic disc brakes, for safe braking even in bad weather
• Front and rear LED lights with brake light, so you’re visible in the city

Technical specifications

• Frame: super-lite AL-6061 aluminum, integrated PowerTube battery
• Motor: Bosch Smart System Performance Line (BDU346Y), 250 W, 36 V
• Maximum assisted speed: 25 km/h
• Battery: Bosch PowerTube 540 Wh, removable
• Gearing: 5-speed Shimano Nexus SG-C7000-5 (internal hub)
• Brakes: Shimano BR-MT200 hydraulic disc brakes
• Fork: Suntour NVX32 NLO DS, 100 mm travel
• Tires: Schwalbe Road Cruiser Plus 55-622, reflective stripe
• Weight: 30.7 kg
• Maximum system weight: 130 kg (bicycle, rider, equipment, and luggage)

Easy to get on and off thanks to the low frame, with a 448 mm step-over height | 250 W Bosch Performance Line motor, assists you up to 25 km/h | 540 Wh PowerTube battery, removable so you can charge it wherever you like | Shimano hydraulic disc brakes, for safe braking even in bad weather | Front and rear LED lights with brake light, so you’re visible in the city

Frame: 28", super-light AL-6061 tubing, PowerTube battery
Fork: Suntour NVX32 NLO DS, 100 mm
Headset: Acros, A-Headset, semi-integrated, tapered, with integrated cable routing
Shift levers: Shimano Nexus, SL-C7000, 5-speed, twist shifter
Brake levers: Shimano BL-MT200, hydraulic disc brake
Brakes: Shimano BR-MT200, hydraulic disc brake
Crankset: Miranda Virage, 170 mm, 38t
Bottom bracket: Bosch, Isis
Handlebar: Syncros 3.0, riser handlebar, backsweep: 40°, rise: 40 mm
Stem: Syncros, with SP Connect mount, adjustable
Pedals: Aluminum trekking
Seatpost: Syncros
Saddle: Syncros Capilano City
Front hub: Shimano HB-QC400, Center Lock, disc, quick release
Rear hub: Shimano Nexus, SG-C7000-5, freehub body, Center Lock, disc
Chain: KMC Z1E HX EPT
Cassette: Shimano, 27t
Spokes: steel, black
Rim: Syncros X17, disc, eyelets
Lights: Front: Lezyne Mini E300, 100 Lux, LED; rear: LED, with brake light function
Accessories: Kickstand: Syncros U-mount
Weight in kg (approx.): 30.7
Motor: Bosch Smart System, Performance Line (BDU346Y), 250 W, 36 V, maximum 25 km/h
Battery: Bosch PowerTube, 36 V Li-ion, 540 Wh
Display: Bosch Purion 200
Charger: Bosch Smart System, 2 A
Brake rotor: Shimano SM-RT10, 180 mm
Grips: Syncros Urban, Ergo, dual-density, lock-on
Front tire: Schwalbe Road Cruiser Plus, reflective stripe, 55-622, inner tube: Schwalbe AV19B Light
Rear tire: Schwalbe Road Cruiser Plus, reflective stripe, 55-622, inner tube: Schwalbe AV19B Light
Luggage rack: Racktime / BGM Trekking Pro, Snapit 2.0 System
Mudguard: Curana Apollo, with stainless steel stays
Gross weight: 130.0 kg, Total weight includes the bicycle, rider, equipment, and any additional luggage.

Bergamont traces its origins to 1993, in a small workshop in Hamburg, and is associated with founder Stefan Berkes. Today it is based in the St. Pauli district and offers gravel bikes, urban and trekking e-bikes, and electric cargo bikes. Its story begins beside the Schlachthof, the city’s historic slaughterhouse.
